MLZ.008001Zoom Lens, 0.7X~4.5X, WD=90mm, C-Mount
- Used for machine vision, scientific research, etc.
- Providing high resolution and high quality image.
- Various adapter and auxiliary Lens for optional.
|
|
|
| Magnification |
0.7X~4.5X |
|
Zoom Ratio
|
1:6.5 |
|
Working Distance
|
90mm |
| Focus Adjustable |
0~3mm |
|
Interface
|
C-Mount |
|
Matching CCD Sensor
|
1/3" 1/2" 2/3" |
| FNO |
14.4 |
| Distortion |
0.15% |
|
| |
|
|
|
| CCD Adapter |
0.5X |
| 0.67X |
| 1.0X |
| 2.0X |
|
Auxiliary Lens
|
0.25X |
| 0.5X |
| 0.75X |
| 1.0X |
| 1.5X |
| 2.0X |
|
| |
|
Adapter and Auxiliary Lens Combination Ratio Table
|
|
Auxiliary Lens
|
WD (mm)
|
CCD Sensor size
|
Adapter 0.5X
|
Adapter 0.67X
|
Adapter 1X
|
Adapter 2X
|
|
|
|
|
0.09X-0.56X
|
0.12X-0.75X
|
0.18X-1.13X
|
0.35X-2.25X
|
|
0.25X
|
302
|
1/3"
|
68.57-10.66
|
51.17-7.96
|
34.28-5.33
|
17.14-2.66
|
|
|
302
|
1/2"
|
|
|
45.71-7.11
|
22.85-3.55
|
|
|
302
|
2/3"
|
|
|
62.85-9.77
|
31.42-4.88
|
|
|
|
|
|
|
|
|
|
0.5X
|
|
|
0.18X-1.12X
|
0.23X-1.50X
|
0.35X-2.25X
|
0.7X-4.5X
|
|
|
176
|
1/3"
|
34.28-5.33
|
25.58-3.98
|
17.14-2.66
|
8.57-1.33
|
|
|
176
|
1/2"
|
|
|
22.85-3.55
|
11.42-1.77
|
|
|
176
|
2/3"
|
|
|
31.42-4.881
|
15.71-2.44
|
|
|
|
|
|
|
|
|
|
0.75X
|
|
|
0.26X-1.69X
|
0.35X-2.26X
|
0.53X-3.38X
|
1.05X-6.75X
|
|
|
117
|
1/3"
|
22.88-3.55
|
17.06-2.65
|
11.43-1.78
|
5.71-0.89
|
|
|
117
|
1/2"
|
|
|
15.24-2.37
|
7.61-1.18
|
|
|
117
|
2/3"
|
|
|
20.95-3.26
|
10.48-1.63
|
|
|
|
|
|
|
|
|
|
None
|
|
|
0.35X-2.25X
|
0.47X-3.00X
|
0.7X-4.5X
|
1.40X-9.00X
|
|
|
96
|
1/3"
|
17.14-2.66
|
12 79-1.99
|
8.57-1.33
|
4.28-0.66
|
|
|
96
|
1/2"
|
|
|
11.42-1.77
|
5.71-0.89
|
|
|
96
|
2/3"
|
|
|
15.71-2.44
|
7.86-1.22
|
|
|
|
|
|
|
|
|
|
1.5X
|
|
|
0.56X-3.38X
|
0.82X-4.52X
|
1.05X-6.75X
|
2.1X-13.5X
|
|
|
50
|
1/3"
|
10.67-1.78
|
7.31-1.33
|
5.71-0.86
|
2.86-0.89
|
|
|
50
|
1/2"
|
|
|
7.61-1.18
|
3.81-1.19
|
|
|
50
|
2/3"
|
|
|
10.48-1.63
|
5.24-1.63
|
|
|
|
|
|
|
|
|
|
2X
|
|
|
0.70X-4.50X
|
0 94X-6.03X
|
1.40X-9.00X
|
2.80X-18.00X
|
|
|
35
|
1/3"
|
8.57-1.33
|
6.40-0.99
|
4.28-0.66
|
2.14-0.33
|
|
|
35
|
1/2"
|
|
|
5.71-0.89
|
2.86-0.44
|
|
|
35
|
2/3"
|
|
|
7.86-1.22
|
3.93-0.61
|
|
|
| |
