| Sensor Resoution |
5.2M,2448x2050 |
| Sensor Type |
Color CCD,ICX655AQ |
| Sensor Size |
2/3"(9.93x8.70) |
| Pixel Size |
3.45x3.45um |
| Frame Rate |
4.3@2448x2050
10.5@960x720 |
| Binning |
1X1 |
| Exposure |
0.12ms~240s |
| Spectral Range |
380-650nm (with IR-filter) |
| White Balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
| Color Rendering Technique |
Ultra Fine Color Engine |
| Capture/Control API |
Native C/C++, C#, Directshow, Twain, Labview |
| Recording System |
Still Picture and Movie |
| Cooling System* |
TE-Cooled CCD - 20 °C below Ambient Temperature |
| Operating Temperature |
-10℃~ 50℃ |
| Storage Temperature |
-20℃~ 60℃ |
| Operating Humidity |
30~80%RH |
| Storage Humidity |
10~60%RH |
| Power Supply |
DC 5V over PC USB Port |
| Operating System |
Support Microsoft Windows XP/ Vista / 7 /8 (32 & 64 bit)
OS X (Mac OS X), Linux |
| Lens Mount |
C-Mount |
| PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or Higher |
| Memory: 2GB or More |
| USB port: USB2.0 High-speed Port |
| CD-ROM |
| Display: 17" or Larger |
