Specification
|
MDS.023075
|
| Magnification | 8x~35x |
| Photo System | Build-in Integrated 5.0 Mega Pixels COMS Camera, Membrane Switch and SD Card Slot |
| Image Output | HDMI port, Analog Video Port(RCA), USB2.0 Port, SD Card 2G. |
|
Head
|
Binocular, 60° Inclined, Built-in 5.0M CMOS Digital Camera, Interpupillary Range 50~75mm
|
|
Eyepiece
|
Wide Filed, High Eyepoint WF10x/22mm, Diopter Adjustment ±5
|
|
Objective
|
0.8x~3.5x Zoom Objective, Zoom Ratio 1:4.4 |
| Working Distance | 95mm |
| Focus | Two focusing knobs are tension adjustable, adjustment range 95mm |
| Illumination
|
Top Illumination: Single 5W high power LED, independent switch, brightness adjustable, angle adjustable |
| Bottom Illumination: Single 5W high power LED, independent switch, brightness adjustable |
