Eyepiece
|
Wide field eyepiece WF16X/11mm
|
|
Dividing 10X/20mm, 0.1mm/Div
|
| Objective
|
Fluorescence objectives FL 40X/1.00 (Spring, Glycerin)
|
Fluorescence objectives FL 100X/1.25 (Spring, Glycerin)
|
| Fluorescence |
100W fluorescence power supply(wide voltage and constant power and calculagraph)
|
|
Reflected Fluorescence
|
Fluorescence filter system UV exciton wavelength:330~400nm
|
|
Fluorescence filter system V exciton wavelength:395~415nm
|
|
Nosepiece
|
Quintuple (Backward ball bearing inner locating)
|
|
Filter
|
Green filter
|
|
Yellow filter
|
|
Phase Contrast Unit
|
Eyepiece: centering telescope
|
|
Phase contrast plan achromatic objective 10X/0.25 PHPl)
|
|
Phase contrast plan achromatic objective 20X/0.40 PHP
|
|
Phase contrast plan achromatic objective 40X/0.65 PHP(Spring)
|
|
Phase contrast plan achromatic objective 100X/1.25 PHP(Spring, oil)
|
|
(PH-I) Turnplate phase contrast condenser
|
|
(PH-II) Turnplate phase contrast condenser
|
|
Flashboard phase contrast condenser
|
|
Pull board phase contrast condenser
|
|
CCD Adapter
|
0.4X
|
|
0.5X
|
|
1X
|
|
0.5X with dividing 0.1mm/Div
|
|
DC Adapter
|
Digital camera adapter CANON (A610,A620,A630,A640)
|
| Photo Adapter |
2.5X/4X Change over photograph adapter with 10X viewing eyepiece
|
|
4X Focusing photograph adapter
|
| PK Adapter |
|
MD Adapter
|
