| Optical System |
UCIS infinity independent achromatic optical system |
| Frame |
One-piece construction from arm to base |
|
|
Seidentopf trinocular head, 30° inclined, interpupillary distance 52-75mm, diopter adjustable
|
|
Eyepiece
|
WF10x/18mm, high eyepoint up to 21mm,, reticule eyepiece, diopter adjustable |
|
WF10x/20mm, plan, high eyepoint up to 21mm
|
|
|
Infinity LWD plan achromatic objective 10x |
|
Infinity LWD plan achromatic objective 20x(s)
|
|
Infinity LWD plan achromatic objective 50x(s)
|
|
Infinity LWD plan achromatic objective 80x(s)
|
| Nosepiece |
Quintuple, reversed type with positive click stops |
| Focusing |
Coaxial coarse and fine focus mechanism with markings. fine focus sensitivity 1μm, coarse range 14mm |
|
|
Low position, mechanical stage, size 180x150mm, moving range 80x50mm. |
| Drop specimen holder(φ110) |
| Specimen holder |
|
Illumination
|
Metallurgical reflected illuminator
|
| 100W halogen lamp house, |
| Electrical parts for 12V 50W halogen lamp |
| 12V50W Halogen bulb (Osram) |
| 250V/5A Φ5X20 Fuse |
| Power supply 110-240V 50/60Hz |
| Filter(Φ32) |
Blue filter |
| Green filter |
| Yellow filter |
| Polarizing Attachment |
Analyzer |
| |
Polarizer |
|
Other
|
Allen screw driver 1.5mm
|
| Allen screw driver 2mm |
| Allen screw driver 3mm |
| Metallurgical micrometer（1/100mm） |
| Dust cover |
| Power cord |
